Lever Operated Butterfly Valve | CI SS304 EPDM PTFE | PN10 PN16 | Project Supply India | IS EN API

Description

Lever Operated Butterfly Valve Supplier India | CI / SS304 / SS316 | PN10 / PN16 / Class 150 | IS 13095 / EN 593 / API 609 | EPC Project Supply | KELOR

Supplier: Krishna Industries (KELOR) – Ahmedabad, Gujarat, India
Established: 2017 | GSTIN: 24AKLPP6499B1ZT | IEC: AKLPP6499B
MOQ: 10 Nos | Standard: EN 593 / BS 5155 / API 609 / IS 13095
Sizes: DN40–DN300 | Rating: PN10 / PN16 / Class 150

Lever Operated Butterfly Valve — Project Supplier in India

Krishna Industries (KELOR), based in Ahmedabad, Gujarat, is a B2B project supplier of Lever Operated Butterfly Valves — Cast Iron (CI IS 210 FG260), Ductile Iron (DI), SS304 (CF8), SS316 (CF8M) body — SS304, SS316, nickel-plated DI disc — EPDM, NBR, PTFE, Viton seat — wafer and lug type — PN10, PN16, Class 150 — DN40 to DN300 — notched lever with 10-position quadrant — EN 558 Series 20 face-to-face — EN 593 / BS 5155 / API 609 / IS 13095 — hydrostatic tested (API 598 / EN 12266) — material test reports (MTR) available — third party inspection (TPI) support — bulk project quantities 50 to 500+ Nos — GST invoice — MOQ 10 Nos — Pan India dispatch from Ahmedabad.

The lever operated butterfly valve — wafer type CI body SS304 disc EPDM seat PN16 — is the single highest-volume butterfly valve specification in Indian EPC, infrastructure, and industrial project procurement. It is specified in water supply projects, HVAC installations, fire fighting systems, effluent treatment plants, irrigation distribution networks, and general industrial pipelines across India. Krishna Industries maintains stock and sourcing capability for project quantities across the full size range DN40 to DN300 with complete compliance documentation support for EPC and PMC approval.

Standard Compliance — Indian Project Specifications

Technical Specifications

Material Combinations — Common Project Specifications

Project Supply — Documentation and Compliance Support

EPC contractors, PMC companies, and industrial project procurement teams require documentation beyond basic supply. Krishna Industries supports the following for project orders:

Wafer vs Lug Type — Project Specification Guide

Wafer type (EN 558 Series 20) is the standard specification for most Indian project applications — both flanged pipe ends must remain in place. Most water supply, HVAC, ETP, fire fighting, and industrial utility project specifications call for wafer type as default.

Lug type (EN 558 Series 16) is specified when: (1) the valve is at a pipeline dead end and one pipe side must be removable independently, (2) the project specification explicitly calls for lug type for maintenance access reasons, or (3) the system design requires end-of-line service capability. Always confirm body style — wafer or lug — when submitting project inquiry to Krishna Industries.

Applications — Indian EPC and Project Sectors

• Water supply and distribution projects — CI SS304 EPDM PN10/PN16 — municipal water treatment plants, pumping stations, overhead tank distribution, AMRUT/JNNURM water supply projects — IS 13095 compliance
• HVAC projects — CI SS304 EPDM PN16 — central plant chilled water, condenser water, cooling tower piping — EN 593 compliance — AHU branch isolation DN50 to DN150
• Fire fighting systems — CI SS304 EPDM PN16 — IS 3844 fire pump discharge, wet riser systems, sprinkler distribution — lug type for end-of-line installation points
• ETP and STP — CI SS304 EPDM PN10/PN16 — effluent and sewage treatment plant piping — inlet distribution, sludge recirculation headers, treated water outlet
• Irrigation infrastructure — CI SS304 EPDM PN10 — main canal distribution, drip and sprinkler system mains, distribution header branch valves
• Industrial utility projects — cooling water, service water, fire water, compressed air distribution — CI or SS304 as per project media and corrosion specification
• Pharmaceutical plant projects — SS316 CF8M PTFE PN16 — purified water, WFI distribution, CIP circuits — GMP compliant, smooth bore
• Food and beverage plant projects — SS316 PTFE PN16 — process water, CIP distribution, utility connections — FDA compatible PTFE seat

Related Products — Krishna Industries (KELOR)

• Hand Operated Butterfly Valve — Selection Guide — detailed guide on lever types, torque limits, size thresholds, notch positions, and when to specify lever vs gear vs actuated
• Gear Operated Butterfly Valve — for DN200 and above or where lever torque is excessive
• PN10 Butterfly Valve — full PN10 pressure rating specifications
• PN16 Butterfly Valve — full PN16 pressure rating specifications
• Lug Type Butterfly Valve — end-of-line installation specifications

Frequently Asked Questions — Project Buyers

1. What standard should I specify for an Indian government water supply tender?

IS 13095 is the Indian standard for butterfly valves and is the correct reference for government PWD, municipal corporation, and water authority tenders. Krishna Industries supplies IS 13095 compliant CI body SS304 disc EPDM seat wafer type lever butterfly valves with compliance documentation. For CPWD projects, also confirm flange drilling pattern — EN 1092-2 (PN) or ASME B16.5 (Class) — to match project piping specification.

2. What is the face-to-face dimension standard for wafer butterfly valves?

EN 558 Series 20 is the standard face-to-face for wafer type butterfly valves — referenced in EN 593 and most Indian EPC project specifications. All wafer butterfly valves supplied by Krishna Industries conform to EN 558 Series 20 face-to-face dimensions, ensuring direct interchangeability with other EN 593 compliant valves on the project.

3. Can you support third party inspection for our project?

Yes — TPI by Bureau Veritas, SGS, Lloyds, EIL, PDIL, and other approved inspection agencies can be arranged. Inform Krishna Industries at order placement stage — TPI requires pre-inspection notification and sufficient lead time before dispatch. Additional TPI charges apply as per inspection agency rates.

4. What documentation comes with a standard project order?

Every project order includes: GST tax invoice, hydro test report (shell + seat leakage per API 598 / EN 12266), packing list, and dispatch documentation. Material test reports (MTR) for body casting and IS 13095 compliance declaration are available on request at order stage — specify documentation requirements in your purchase order.

5. Can you supply mixed sizes in a single project order?

Yes — project orders with multiple sizes (e.g. 20 Nos DN80 + 15 Nos DN100 + 10 Nos DN150) are handled as a single order with consolidated dispatch and a single invoice. Minimum 10 Nos total applies. WhatsApp your full size-wise BOM (bill of materials) for project pricing.

6. What is the delivery lead time for a project order of 100+ Nos?

For standard CI SS304 EPDM wafer type DN50 to DN150 — stock availability confirmed at inquiry stage — typically 5 to 7 working days for up to 200 Nos. For SS304/SS316 body or larger sizes DN200 to DN300 — 10 to 15 working days. Urgent project requirements can be discussed — call or WhatsApp with complete size list and delivery deadline.

Conclusion

The Lever Operated Butterfly Valve supplied by Krishna Industries (KELOR) is the standard specification for Indian water supply, HVAC, fire fighting, ETP, irrigation, and industrial project procurement — CI (IS 210 FG260), DI, SS304 (CF8), SS316 (CF8M) body — EPDM, NBR, PTFE, Viton seat — wafer and lug type — PN10, PN16, Class 150 — DN40 to DN300 — EN 593 / BS 5155 / API 609 / IS 13095 — API 598 / EN 12266 hydro tested — MTR and TPI support for EPC projects. Bulk project quantities 50 to 500+ Nos, complete documentation package, GST invoice, Pan India dispatch from Ahmedabad. WhatsApp your project BOM for bulk pricing within 2 hours.
