Description

PN16 Butterfly Valve | CI / DI / WCB / SS304 / SS316 | Wafer & Lug Type

Supplier: Krishna Industries (KELOR) – Ahmedabad, Gujarat, India
Established: 2017 | GSTIN: 24AKLPP6499B1ZT | IEC: AKLPP6499B
MOQ: 10 Nos | Sizes: 50mm–600mm | Pressure: PN16 (16 Bar)

---

Introduction – PN16 Butterfly Valve Supplier India

Krishna Industries (KELOR), based in Ahmedabad, Gujarat, India, is a trusted B2B supplier of PN16 Butterfly Valves sourced from verified Indian manufacturers. We supply PN16 Butterfly Valves across all major material grades — Cast Iron (CI), Ductile Iron (DI), Carbon Steel (WCB), Stainless Steel SS304, and Stainless Steel SS316 — with EPDM, NBR, Viton, and PTFE seat options — sizes 50mm to 600mm — in wafer type and lug type configurations.

The PN16 Butterfly Valve is rated for 16 bar (232 PSI) nominal pressure — higher than the standard PN10 rating — making it the correct specification for pumping mains, industrial process piping, chemical plant lines, fire fighting pump discharge headers, and any Indian EPC project where operating pressure exceeds 10 bar or where the project specification explicitly calls for PN16.

We supply PN16 Butterfly Valves to EPC contractors, purchase managers, plant maintenance MRO teams, fire fighting contractors, chemical plant procurement departments, and bulk industrial buyers across Gujarat and PAN India. All supplies come with GST invoices, Material Test Certificates (MTC), and complete B2B documentation.

Also referred to as: PN16 BFV, 16 bar butterfly valve, PN16 wafer butterfly valve, PN16 lug butterfly valve, Class 125 butterfly valve — all referring to the same higher-pressure rated butterfly valve used in Indian industrial and infrastructure projects requiring pressure ratings above PN10.

---

PN16 vs PN10 — Which Butterfly Valve Does Your Project Need?

This is the most important question EPC engineers and purchase managers ask when specifying butterfly valves. Here is a clear guide:

Factor	PN10 Butterfly Valve	PN16 Butterfly Valve
Pressure Rating	10 Bar (145 PSI)	16 Bar (232 PSI)
Cost	More economical	Slightly higher — heavier body
Typical Use	Water supply, HVAC, irrigation, STP/ETP	Pumping mains, industrial process, fire fighting headers
Fire Fighting	Distribution piping	Pump discharge headers — PN16 recommended
Chemical Plant	Low-pressure utility	Process line isolation — PN16 standard
Pumping Mains	Not recommended above 10 bar	✅ Correct specification
Project Spec Says	PN10 or 10 bar	PN16, 16 bar, or Class 125
When Unsure	Use if pressure confirmed below 10 bar	✅ Safer choice for critical service

Rule of thumb for Indian EPC projects: Always match the valve pressure rating to your project’s design pressure — not operating pressure. If design pressure is 12 bar, specify PN16 not PN10. Krishna Industries can assist with correct specification — WhatsApp us your project details.

---

Complete Material Combination Guide — All Available Variants

Body Material Options

Body Material	Grade	Best For	Typical Application
Cast Iron (CI)	IS 210 Gr FG 260	Most economical — general water and utility service	Water mains, pumping stations, STP, ETP, HVAC
Ductile Iron (DI)	IS 1865 / EN-GJS-400	Higher strength — better for higher pressure mains	Pumping mains, water distribution, industrial utilities
Carbon Steel (WCB)	ASTM A216 WCB	Industrial process service — higher temp and pressure	Industrial process lines, power plants, petroleum
Stainless Steel 304	CF8 / ASTM A351	Corrosion-resistant — moderate chemical service	Chemical plant utilities, pharma water, food processing
Stainless Steel 316	CF8M / ASTM A351	Maximum corrosion resistance	Aggressive chemical, pharmaceutical GMP, coastal

Disc Material Options

Disc Material	Best For	Typical Application
Ductile Iron with Nickel Coating	General water and utility — most economical	Water supply, HVAC, STP, ETP, pumping stations
Stainless Steel SS304	Corrosion-resistant — moderate chemical duty	Chemical plant, food processing, pharma utilities
Stainless Steel SS316	Maximum corrosion resistance	Aggressive chemical, coastal, pharmaceutical GMP
Aluminium Bronze	Marine and seawater service	Offshore, coastal, desalination projects
Nylon Coated Disc	Food grade — non-contaminating	Food and beverage, potable water service

Seat / Liner Material Options

Seat Material	Temperature Range	Best For	Typical Application
EPDM	-10°C to +120°C	Water, hot water — most common in India	Water mains, HVAC, pumping stations, fire fighting
NBR (Nitrile)	-20°C to +80°C	Oil, fuel, petroleum products	Fuel lines, petroleum utilities, oil handling systems
Viton (FKM)	-20°C to +180°C	Chemical resistance and high temperature	Chemical plant, solvents, acids, high temp service
PTFE	-20°C to +150°C	Aggressive chemical and pharmaceutical service	Pharmaceutical GMP, strong acids, aggressive media

Mounting Type Options

Type	Installation	Best For
Wafer Type	Sandwiched between two flanges using through-bolts	Most economical — both sides of pipeline always connected
Lug Type	Threaded lugs bolt independently to each flange	One-side isolation — pipeline section removal for maintenance

Operation Options

Operation Type	Suitable Size	Best For
Lever Operated (Manual)	50mm – 200mm	Frequent manual operation, simple on/off isolation
Gear Operated (Gearbox)	200mm – 600mm	Large diameter — smooth low-effort manual operation
Pneumatic Actuator	50mm – 400mm	Automated remote operation, process control
Electric Actuator	50mm – 400mm	PLC controlled systems, SCADA integration

---

Technical Specifications – PN16 Butterfly Valve

Parameter	Specification
Nominal Pressure	PN16 (16 Bar / 232 PSI)
Design Standard	BS EN 593, IS 13095, API 609
Face to Face	BS EN 558 Series 20 (Short Pattern)
Actuator Mounting	ISO 5211 (Actuator Ready)
Size Range	50mm to 600mm (2″ to 24″) — larger on request
End Connection	Wafer / Lug — ANSI B16.5 / DIN / IS Standard Flanges
Shaft Material	Stainless Steel 420 / 304
Testing Standard	BS EN 12266 / API 598
Temperature Range	-10°C to +180°C (seat material dependent)
MOQ	10 Nos
HSN Code	84818010

---

All Material Variants — Full Keyword Coverage

Krishna Industries supplies the following PN16 Butterfly Valve variants for Indian industrial and EPC projects:

Cast Iron PN16 butterfly valve EPDM seat wafer type supplier India. Cast Iron PN16 butterfly valve NBR seat lug type supplier Ahmedabad. Cast Iron body SS304 disc PN16 butterfly valve EPDM seat India. Ductile Iron PN16 butterfly valve SS disc EPDM seat supplier Gujarat. Ductile Iron PN16 lug type butterfly valve gear operated India. WCB carbon steel PN16 butterfly valve EPDM seat wafer type supplier India. SS304 PN16 butterfly valve CF8 body PTFE seat supplier India. SS316 PN16 butterfly valve CF8M body Viton seat chemical service India. SS316 body SS316 disc PN16 butterfly valve PTFE seat pharmaceutical India. Gear operated PN16 butterfly valve 200mm to 600mm supplier India. Lever operated PN16 butterfly valve 50mm to 200mm Ahmedabad. Pneumatic actuated PN16 butterfly valve supplier India EPC. Electric actuated PN16 butterfly valve PLC control supplier India. PN16 wafer butterfly valve CI body SS disc bulk supply EPC India. PN16 lug butterfly valve isolation service supplier Ahmedabad Gujarat.

---

Applications in Indian Industries

PN16 Butterfly Valves are specified wherever operating or design pressure exceeds 10 bar, or where project specifications explicitly call for PN16 rating:

• Pumping station discharge mains and pressure mains — PN16 standard specification
• Fire fighting pump discharge headers — PN16 mandatory per IS 15105 / NBC
• Municipal water supply high-pressure distribution mains
• Water treatment plants — high-pressure process lines
• Industrial process piping in chemical and petrochemical plants
• Pharmaceutical plant high-pressure process utilities
• HVAC high-rise building chilled water mains — PN16 required above certain floors
• Power plant cooling water and auxiliary systems
• Irrigation pumping mains and canal head works
• Sugar mills, cement plants, and heavy industrial utilities
• EPC infrastructure projects where project spec mandates PN16

---

EPC Contractors — Bulk PN16 Butterfly Valve Supply

Krishna Industries supports EPC project procurement with complete bulk supply capability:

• Bulk quantity supply from MOQ 10 Nos upwards
• Material Test Certificates (MTC) for all valves
• Hydrostatic test certificates on request
• GST invoices — GSTIN: 24AKLPP6499B1ZT — for full input tax credit
• E-way bill and delivery challan for PAN India transport
• Fast dispatch from Ahmedabad — 2 to 5 working days PAN India transit
• Technical support for material grade, seat, type, and actuation selection
• Competitive project-rate bulk pricing with confirmed lead times

As a multi-product B2B supplier, Krishna Industries consolidates PN16 Butterfly Valves with PN10 Butterfly Valves, Lug Type Butterfly Valves, Wafer Check Valves, Ball Valves, Flanges, Pipe Fittings, and Fasteners in single orders with single GST invoice — reducing EPC procurement workload significantly.

---

Purchase Managers and MRO Buyers

• MOQ 10 Nos — accessible for maintenance and top-up quantities
• Exact spec matching — material grade, pressure rating, size verified before supply
• Replacement seat liners available separately for in-situ maintenance
• Consistent batch quality from same verified manufacturer
• Fast repeat order processing — share previous order details for quickest response
• Complete GST invoice documentation for accounts compliance

---

PAN India Supply Coverage

Krishna Industries dispatches PN16 Butterfly Valves from our Ahmedabad warehouse to all major Indian states and cities:

Maharashtra — Mumbai, Pune, Navi Mumbai, Nashik, Aurangabad, Nagpur
Gujarat — Ahmedabad, Surat, Vadodara, Rajkot, Bharuch, Ankleshwar, Vapi
Rajasthan — Jaipur, Jodhpur, Udaipur, Kota, Bhilwara
Delhi NCR — Delhi, Noida, Gurgaon, Faridabad, Ghaziabad
Tamil Nadu — Chennai, Coimbatore, Madurai, Tirupur, Salem
Karnataka — Bangalore, Hubli, Mysore, Belgaum, Mangalore
Telangana and Andhra Pradesh — Hyderabad, Vizag, Vijayawada, Kakinada
Madhya Pradesh — Indore, Bhopal, Jabalpur, Pithampur
Punjab and Haryana — Ludhiana, Amritsar, Chandigarh, Panipat
West Bengal — Kolkata, Durgapur, Asansol, Haldia
Odisha, Jharkhand, Chhattisgarh — all industrial zones

Export supply available FOB Mundra / JNPT for UAE, Saudi Arabia, Vietnam, and other markets. IEC registered exporter — IEC: AKLPP6499B.

---

Quality and Documentation

• Material Test Certificate (MTC) from manufacturer
• Hydrostatic test certificate on request
• Dimensional inspection records
• GST invoice — GSTIN: 24AKLPP6499B1ZT
• Industrial packaging with size, material, and pressure rating labeling
• E-way bill and delivery challan for PAN India transport

---

Related Products from Krishna Industries (KELOR)

• PN10 Butterfly Valve — economical lower pressure alternative for water and HVAC service
• Lug Type Butterfly Valve — one-side pipeline isolation capability
• CI Wafer Check Valve — backflow prevention on pump discharge lines
• SS 304 Wafer Check Valve — corrosion-resistant NRV for chemical service
• Flanged Ball Valve — high-pressure isolation for process lines
• Forged 3 Piece Ball Valve — high-cycle isolation in process plants

All available from Krishna Industries with single GST invoice and consolidated PAN India dispatch.

---

Frequently Asked Questions

1. What does PN16 mean in butterfly valve?

PN16 refers to the nominal pressure rating of 16 bar (232 PSI). This valve is designed and tested for fluid pressures up to 16 bar — higher than the standard PN10 — making it suitable for pumping mains, fire fighting headers, industrial process lines, and high-pressure EPC projects across India.

2. When should I use PN16 instead of PN10?

Use PN16 when your project design pressure exceeds 10 bar, when project specification explicitly states PN16, for fire fighting pump discharge headers (mandatory PN16 per Indian NBC and IS 15105), for pumping mains, and for industrial process isolation where higher pressure margin is required.

3. Is PN16 butterfly valve mandatory for fire fighting systems?

Yes — Indian fire fighting standards and NBC (National Building Code) typically mandate PN16 rating for pump discharge headers and main distribution piping. Always check your project fire fighting specification — PN16 is the safe standard choice for fire fighting pump headers.

4. What body material should I choose?

CI or DI for water mains and pumping stations. WCB for industrial process lines. SS304 for moderate chemical and corrosion-resistant service. SS316 for aggressive chemical, pharmaceutical, and coastal applications.

5. What seat material for water and pumping mains?

EPDM is the standard and most widely used seat material for water mains, pumping stations, HVAC, and fire fighting applications across India.

6. What is the difference between wafer type and lug type PN16?

Wafer type sandwiches between two flanges — economical, both sides always connected. Lug type bolts independently to each flange — allows one-side pipeline removal for maintenance. Choose lug type where maintenance access or one-side isolation is required.

7. What sizes are available?

50mm to 600mm (2 inch to 24 inch). Larger sizes available on request.

8. Can the valve be automated?

Yes — all valves are supplied with ISO 5211 actuator mounting pad. Pneumatic and electric actuator packages available from 50mm to 400mm.

9. Do you provide GST invoice and MTC?

Yes — every order includes GST invoice (GSTIN: 24AKLPP6499B1ZT) and Material Test Certificate. Hydrostatic test certificates available on request.

10. What is the MOQ?

MOQ is 10 Nos. Bulk project orders welcome with better pricing and confirmed delivery timelines.

11. Can I order PN16 and PN10 butterfly valves together in one order?

Yes — Krishna Industries supplies multiple valve types and pressure ratings in consolidated single orders with single GST invoice — reducing EPC procurement complexity and logistics cost.

12. Do you supply for export?

Yes — IEC registered exporter (IEC: AKLPP6499B). Export supply FOB Mundra or JNPT to UAE, Saudi Arabia, Vietnam, and other markets.

---

Conclusion

The PN16 Butterfly Valve supplied by Krishna Industries (KELOR) is a reliable BS EN 593 / IS 13095 / API 609 compliant higher-pressure butterfly valve — available in Cast Iron, Ductile Iron, WCB, SS304, and SS316 body — EPDM, NBR, Viton, and PTFE seat — wafer and lug type — sizes 50mm to 600mm — lever, gear, pneumatic and electric actuator operation. Sourced from verified Indian manufacturers and supplied with complete MTC, GST documentation, and fast PAN India dispatch from Ahmedabad.
