Dual Plate Check Valve

Description

KELOR Dual Plate Check Valve – Manufacturer, Supplier & Exporter

The KELOR Dual Plate Check Valve, also known as a Double Door Wafer Check Valve, is engineered for efficient backflow prevention in modern pipeline systems. Its compact wafer-type design and spring-assisted dual plates ensure quick response to flow reversal, significantly reducing water hammer and protecting downstream equipment.

Designed in accordance with API 594, API 6D (where applicable), ASME B16.34, and international testing standards, KELOR dual plate check valves are suitable for installation between ANSI, DIN, BS, and JIS flanges. The lightweight construction reduces installation cost while maintaining excellent structural strength and sealing reliability.

The valve features two spring-loaded plates mounted on a central hinge pin. This configuration allows the plates to open smoothly with forward flow and close rapidly when flow stops, ensuring tight shut-off performance and minimal pressure loss. The short face-to-face dimension makes it ideal for space-constrained piping layouts.

KELOR manufactures dual plate check valves using high-grade materials such as Ductile Iron, Carbon Steel (WCB), and Stainless Steel (CF8 / CF8M), with elastomer and metal seat options to match diverse media and temperature requirements. Precision machining, robust springs, and corrosion-resistant coatings ensure long-term reliability even in demanding service conditions.

These valves are widely used in water distribution, HVAC systems, fire protection lines, oil & gas pipelines, chemical processing, power plants, and industrial utilities. Every valve undergoes strict quality inspection and hydrostatic testing to deliver dependable, leak-free performance.

KELOR, based in India, is committed to supplying globally competitive flow control solutions by combining engineering expertise, advanced manufacturing, and rigorous quality assurance. Bulk supply and export packaging are available on request.

Applications

• Water supply & distribution pipelines
• HVAC and chilled water systems
• Fire fighting networks
• Oil & gas and refinery utilities
• Chemical and process industries
• Power plants and industrial utilities

Key Advantages

• Compact wafer design with short face-to-face
• Low pressure drop and energy-efficient flow
• Spring-assisted fast closing to minimize water hammer
• Bidirectional installation flexibility
• Easy installation and low maintenance

Technical Specifications

Material of Construction

Frequently Asked Questions (FAQ)

1. What is a dual plate check valve?
   A dual plate check valve uses two spring-loaded plates to prevent reverse flow while maintaining low pressure drop.
2. What are the advantages over swing check valves?
   Dual plate check valves are lighter, more compact, close faster, and significantly reduce water hammer.
3. Can the valve be installed vertically or horizontally?
   Yes, KELOR dual plate check valves can be installed in both orientations, subject to flow direction.
4. Which industries commonly use this valve?
   Water treatment, HVAC, oil & gas, chemical processing, power plants, and fire protection systems.
5. What flange standards are supported?
   ANSI, DIN, BS, and JIS flanges are supported due to the universal wafer design.
6. What materials are available?
   Ductile iron, carbon steel, stainless steel, and special alloys on request.
7. Is the valve suitable for high temperature service?
   Yes, depending on seat and spring material selection, temperatures up to 200 °C are possible.
8. Does it require frequent maintenance?
   No. The simple internal mechanism ensures long service life with minimal maintenance.
9. Is bulk supply available for projects?
   Yes, KELOR specializes in bulk orders for industrial and infrastructure projects.
10. Does KELOR export dual plate check valves?
    Yes, KELOR is a reliable Manufacturer, Supplier & Exporter serving domestic and international markets.
